2D and 3D laser cutting of tubes and profiles, from LT7 and LT8 work to large LT14 structural components.

• LT7/LT8 maximum round diameters: 152/240 mm; raw lengths: 6.5/12 m; finished lengths: 6.5 m.
• LT14: round tubes 30–356 mm, square profiles up to 260 × 260 mm, rectangular profiles up to 300 × 200 mm and length up to 15 m; limits depend on profile and material.

Laser cutting and punching produce sheet parts, perforations and formed features for prototypes and series production.

Deburring, tapping, countersinking and fastener insertion complete cut or formed metal parts.

• Rösler vibratory finishing; Fladder and Timesavers brush deburring up to 1350 mm wide.

CNC rolling and press-brake bending form cylindrical, curved and folded sheet components.

• Haeusler rolling width up to 2 m.
• Press-brake limits: 4000 mm length, 260 tonnes force and 30–180° angles; feasible combinations depend on the part.

Manual and robotic welding joins carbon steel, stainless steel and aluminium, with carbon-steel and stainless work separated.

Mechanical assembly combines fabricated parts with coordinated partner machining and surface treatments for finished delivery.

• Approximately 6000 m² dedicated to assembly and completion.
• External CNC machining, tube bending and surface treatments are executed by partners.

CAD-based prototype printing on a Stratasys F170 with a 254 × 254 × 254 mm build envelope.

Manufacturing support from idea and drawing optimization through production, external processing and finished delivery.

Stainless-steel processing and welding for custom medical equipment components, with surface treatment for corrosion resistance.

Tube and sheet fabrication for food equipment, combining laser cutting, welding and custom assemblies.

Order-level material, batch and process records, including production photographs and work instructions.
