Technical details

Cylinder-tube bore tolerances

Honed/roller-burnished E355+SR: ISO H8; bright-drawn E355+C: ISO H9/H10 with Ra ≤0.8 µm.

Hollow-bar clean-machined dimension conditions

EN 10294-1 E470: external centring, length up to 3 × outside diameter and at most 200 mm; nominal dimensions vary by manufacturer.

NiKrom 500 coating and tolerance

Nickel ≥30 µm, chromium ≥20 µm, ISO f7; applies to named piston-rod family.

Ground-bar tolerance

C45E and 20MnV6 centreless-ground bars: ISO h8.

Stainless-fitting sizes

DN 15–DN 600 for the listed elbow, reducer, tee and collar families; pressure ratings and material must be selected per fitting.

Seamless stainless tube delivery

EN 10216-5 TC1/TC2; ISO 1127 tolerances; 5–7 m manufacturing lengths.

Cold-drawn bar delivery

Named S355J2+C and free-machining grades: ISO h9 per EN 10278, generally 3 m; 2142/06 line lists 6 m.

Custom-profile supply limits

Open profiles: approximate height 300 mm, wall 0.3–12.5 mm; welded profiles: approximate height 200 mm, wall 1–7 mm. Both tables list length up to 24000 mm. Not a Danish-machine envelope or promise that maxima combine.

Material-document availability

EN 10204 3.1 documentation for boiler families and by agreement for several tube families; stainless welded-tube options use 3.1 or 2.2.

Group and Danish operating history

Group founded in Halmstad in 1927 and joined Van Leeuwen in 2019. Danish page describes tube-laser supply since the early 2000s. These dates do not establish Danish legal incorporation.

Welded cold-drawn precision tube delivery

E235 +C/+N to EN 10305-2; 5–7 m supply lengths; wall tolerance ±7.5%, minimum ±0.1 mm, subject to delivery-condition dimensional rules

Welded precision tube delivery

E220+CR2, S2/S3 surfaces; round tubes to EN 10305-3; 6000/6100 mm catalogue lengths; stated surface values exclude the weld zone

Seamless hot-rolled tube grades

S355J2H to EN 10210-1/2; E355 to EN 10297-1; P355N TC1 to EN 10216-3; impact test minimum 27 J at −20 °C and batch marking

Alloy bar grades

34CrNiMo6+QT, 25CrMoS4+QT, 16NiCrS4+HL and 42CrMoS4+QT; rolled, peeled and forged supply options vary by grade

Non-alloy bar grades

S355J2, forged S355J2+N, C45R+H, forged C45+N and 2142IM/S355SVA machining grades; S355J2 impact minimum 27 J at −20 °C

Cold-drawn bar grades

S355J2+C, 11SMnPb30+C, 11SMn30+C and 36SMnPb14+C; shapes and supply condition vary by grade

Stainless line and dairy tube delivery

EN 10217-7 and EN 10357 families; 6000 mm, −0/+100 mm; dairy finishes CCM, BC, CD and BD

Stainless structural tube delivery

EN 10296-2; TIG/HF manufacture; untreated or K240/K320 finish; 6000 mm, −0/+100 mm

Stainless square and rectangular tube delivery

Grades 1.4301, 1.4404 and 1.4571; untreated, brushed or K320; 6000 mm, −0/+100 mm

Stainless bar delivery

Drawn/ground round bars in 1.4301, 1.4305, 1.4307, 1.4404 and 1.4571; ISO h9; 3–6 m lengths

Rebated profile delivery

S235JRG2; 6000 mm, +50/−0 mm; galvanised or 1.4301 alternatives and custom lengths

Water-line tube supply diameter

80–1800 mm; maximum diameter tolerance ±3 mm for the described water-line programme

EN boiler-family materials

P235GH TC1/TC2 tubes to EN 10216-2; P235GH fittings to EN 10253-2 Type A/B; P250GH flanges to EN 1092-1 types 02, 05 and 11; EN 10204 3.1 documentation

ASTM boiler-family materials

A106/B and A333/6 tubes; A234/WPB and A420/WPL6 fittings; A105 and A350/LF2 flanges; EN 10204 3.1 documentation

Electrogalvanised hydraulic tube coating

Minimum 12 µm or 25 µm coating options, Cr(VI)-free and thick-film passivated; E235/E355 to EN 10305-4

Middelfart warehouse assortment

2,300 tonnes of tube and bar products in the dehumidified warehouse; stated assortment, not a live stock balance

Special welded hydraulic tube testing and delivery

Normalized E195 tubes for oil and hydraulic lines; internal weld seam up to 0.3 mm; outside diameter 5–12 mm helium-leak tested at 35 bar, larger diameters eddy-current tested; normally 6000 mm.
